Saldi

Bullet IP AI 4 MP 8~56 mm LED High Temp. Tolerance

Name: Bullet IP AI 4 MP 8~56 mm LED High Temp. Tolerance
Brand: Dahua
SKU: IPC-HFS8449G-Z7-LED
Price: 2308.24 EUR
Availability: BackOrder

Dahua

COD: IPC-HFS8449G-Z7-LED Categorie: Telecamere IP, Videosorveglianza Tag: 4MP

2.308,24 € IVA inclusa

Prezzo precedente più basso negli ultimi 30 giorni: 4.616,48 €

Installatore o Rivenditore?
Registrati oppure Accedi per vedere il prezzo riservato.

Compara

Caratteristiche Specifiche tecniche Download

Telecamera bullet IP AI WizMind Polarlight High Temperature Tolerance (24/7 ≤75° C, 12 h ≤85° C) da interno/esterno IP67, H.265+, sensore CMOS progressivo 1/1.8", risoluzione 4 MP a 25fps, ottica motorizzata 8~56 mm ƒ1.2, portata LED fino a 80 m, 1 porta LAN 10/100/1000 Mbps, 1 porta RS485, 3 ingressi e 2 uscite allarme, 2 ingressi e 1 uscita audio, privacy mask 4 aree, time-division exposure, Hyper DoF, 3D NR, WDR 120 dB, oggetto abbandonato/mancante, IVS (protezione perimetrale), face detection/recognition, people counting, metadati video, micro SD card (256 GB), alimentazione 100~240 Vac <26 W, staffa da parete PFB605W-SG inclusa

Datasheet

Scheda Tecnica

Manuali

Disegni

Disegni Dimensionali

Camera
Image Sensor	1/1.8" CMOS
Max. Resolution	2688 (H) × 1520 (V)
ROM	8 GB
RAM	4 GB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s–1/100,000 s 0.0003 lux@F1.2(Color, 30 IRE)
Min. Illumination	0.0001 lux@F1.2 (B/W, 30 IRE) 0 lux (Illuminator on)
S/N Ratio	56 dB >
Illumination Distance	80 m (262.47 ft) (warm light)
Illuminator On/Off Control	Auto; Zoomprio; Manual
Illuminator Number	6 (warm light)
Lens
Lens Type	Motorized vari-focal
Lens Mount	Module
Focal Length	8 mm–56 mm
Max. Aperture	F1.2 H: 41°–9°
Field of View	V: 23°–5° D: 47°–11°
Iris Control	Auto
Close Focus Distance	1 m (3.28 ft)
Dori
Distance	640 m 256 m 128 m 64 m T (2099.73 ft) (839.90 ft) (419.95 ft) (209.97 ft)
Smart Event
IVS	Abandoned object; missing object
Intelligence
IVS (Perimeter Protection)	of vehicle and human); loitering detection, people gathering, and parking detection Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and
Face Detection	8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting.
Face Recognition	inch photo; snapshot strategies (recognition priority and optimization snapshot); face angle filter; optimization time setting. Supports adding 5 group face databases; registering person one by one or in batches; setting face similarity; and supports face comparison with the face database containing up to 100,000 face pictures. Tripwire people counting and people counting in area, generating and exporting report (day/month/year);
People Counting	queue management, generating and exporting report (day/month); 4 rules can be set for tripwire, people counting in area and queue management Motor vehicle, non-motor vehicle, face, and human body detection; snapshot; snapshot optimization; optimal face snapshot upload. Motor vehicle attributes: License plate, plate color, vehicle color, vehicle logo, vehicle year, sun visor, seatbelt, smoking, calling, ornament, and annual
Video Metadata	inspection sticker and more. Non-motor vehicle attributes: Type, vehicle color, number of people, top type and color, and hat. Human body attributes: Top and bottom type and color, bag, hat, and gender. Face attributes: Gender, age, expressions, glasses, face mask, and bread. Work together with Smart NVR to perform refine
Smart Search	intelligent search, event extraction and merging to event videos
Video
Video Compression	by the sub stream)
Smart Codec	Smart H.265+; Smart H.264+ Main Stream: 2688 × 1520@(1–25/30 fps) sub stream: 1920 × 1080@(1–25/30 fps) third stream: 1920 × 1080@(1–25/30 fps)
Video Frame Rate	fourth stream: 1920 × 1080@(1–25/30 fps) fifth stream: 704 × 576@(1–25 fps); 704 × 480@(1–30 fps)
Stream Capability	5 streams 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296);
Resolution	1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control	CBR/VBR H.264: 32 kbps–10240 kbps;
Video Bit Rate	H.265: 12 kbps–9472 kbps
Day/Night	Color
BLC	Yes
HLC	Yes
WDR	120 dB
Scene Self-adaptation	Yes
(SSA)	Auto; natural; street lamp; outdoor; manual; regional
White Balance	custom
Gain Control	Auto; Manual
Noise Reduction	3D NR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest (RoI)	Yes (4 areas)
Image Stabilization	Electronic Image Stabilization (EIS)
Smart Illumination	Yes
Defog
Image Rotation	and lower)
Mirror	Yes
Privacy Masking	4 areas
Time-Division Exposure	Yes
Audio
Audio Compression	G.729
Alarm
Alarm Event	detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; face recognition; people counting in area; people counting; people number error detection; security exception
Network
Network Port	RJ-45 (10/100/1000 Base-T)
SDK and API	Yes IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP;
Network Protocol	SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; Milestone
User/Host	20
Storage
Browser	Chrome: 88.0.4324.190 and earlier; Firefox: 47.0.2 and earlier
Management Software	Smart PSS; DSS;
Mobile Client	iOS; Android Configuration encryption;trusted execution; Digest; security logs; WSSE; account lockout; syslog; video
Cyber Security	encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification
Port
RS-485	1 (baud rate range: 1200 bps–115200 bps)
Audio Input	2 channels (RCA port)
Audio Output	1 channel (RCA port)
Alarm Input	3 channels in: 5 mA 3–5VDC
Alarm Output	2 channels out: 1,000 mA 30 VDC/500 mA 50 VAC
Power
Power Supply	100–240 VAC 0.6 A Basic: 22.5 W (220 V)
Power Consumption	Max. (Basic+ WDR+ Intelligence on + Illuminator on + Lens switching): 26 W (220 V)
Environment
Operating Temperature	–30 °C to +75 °C (–22 °F to +167 °F)
Operating Humidity	≤95%
Storage Temperature	–30 °C to +75 °C (–22 °F to +167 °F)
Protection	IP67
Structure
Casing Material	Metal + plastic 513.14 mm × 177.09 mm × 190.7 mm (20.20" × 6.97" ×
Product Dimensions	7.50") (L × W × H)
Net Weight	4.8 kg (10.58 lb)
Gross Weight	6.45 kg (14.22 lb)
Ordering Information
Type	Model Description 4MP High Temperature Tolerance DH-IPC-HFS8449G-Z7-LED WizMind Network Camera
Optional:
DH-PFA150-SG	DH-PFA162-SG Integrated Pole Mount Pole Mount Mount Tester Bracket Bracket TF-P100 MicroSD
Memory Card	The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product.
