Controller web server 2 varchi 2/2 I/O allarme

Name: Controller web server 2 varchi 2/2 I/O allarme
Brand: Dahua
SKU: ASC3202B
Price: 357.46 EUR
Availability: BackOrder

Dahua

COD: ASC3202B Categorie: Controller controllo accessi, Controllo Accessi

357,46 € IVA inclusa

Prezzo precedente più basso negli ultimi 30 giorni: 714,92 €

Installatore o Rivenditore?
Registrati oppure Accedi per vedere il prezzo riservato.

Compara

Caratteristiche Specifiche tecniche Download

Centralina per controllo accessi a 2 varchi con web server integrato e configurazione web, da interno IK06, 1 porta LAN 10/100 Mbps, 3 porte RS485 e 2 Wiegand, 2 pulsanti apertura porta, 2 ingressi per sensore stato porta, 2 ingressi e 2 uscite allarme, 2 ingressi lettore RS-485 e 2 Wiegand, allarme apertura porta, intrusione, duress (anche impronta), tamper, sblocco tramite card, password, impronta digitale e da remoto (anche in combinazione), 1000 utenti, 5000 card, 3000 impronte e 300000 eventi, alimentazione 12 Vdc/PoE

Datasheet

Scheda Tecnica

Manuali

Disegni

Disegni Dimensionali

System
Main Processor	Embedded processor
Internet Protocol	P2P; IPv4; DNS; DDNS; TCP; UDP
Interoperability	ONVIF; CGI
SDK and API	Yes
Basic
Product Type	Controller
Buzzer	Yes
Casing Material	PC + ABS
Function
Unlock Mode	combination unlock
Period List	128 periods
Holiday Period	128 periods
Network Update	Yes
Blocklist/Allowlist	Yes Supports 2 × RS-485 card readers; 2 × Wiegand
Peripheral Card Reader	card readers
Multi-user Authentication	Yes (Use with platform)
Real-time Monitoring	Yes
Multi-factor Authentication	Yes
Web Configuration	Yes
User
User (Card) Type	blocklist user, and other users
Capacity
User Capacity	mode)
Fingerprint Capacity	3,000 5,000 (main control mode), 50,000 (sub control
Card Capacity	mode)
Bluetooth Card Capacity	5,000
Record Capacity	300,000
Port
RS-485	3
Wiegand	2 × input
Network Port	1 × RJ-45 10/100 Mbps Ethernet port
Alarm Input	2 (digital quantity)
Alarm Output	2 (digital quantity)
Alarm Linkage	Yes
Exit Button	2
Door Status Detection	2
Lock Control	2
Alarm
Tamper Alarm	Yes
Duress Alarm	Yes
Door Sensor Timeout	Yes
Intrusion	Yes
Illegal Card Exceeding	Yes
Duress Fingerprint	Yes
General
Power Supply	802.3at Type 2 Class 4
Protection	IK06 Standby Power (no peripheral devices): ≤2 W Working Power:
Power Consumption	Total power budget if powered by DC: 1700 mA at 12 V for peripheral devices (locks, readers etc.) Total power budget if powered by PoE: 1200 mA at 12 V for peripheral devices (locks, readers etc.) 186.4 mm × 185.8 mm × 58.3mm (7.34" × 7.31" ×
Product Dimensions	2.30") (L × W × H) 254 mm × 243 mm × 86 mm (10.00" × 9.57" × 3.39")
Packaging Dimensions	(L × W × H)
Operating Temperature	–10 °C to +55 °C (+14 °F to 131 °F)
Operating Humidity	5%–95% (RH), non-condensing
Operating Environment	Indoor
Gross Weight	0.99 kg (2.18 lb)
Installation	Surface Mount; Guide Rail Mount
Ordering Information
Type	Model Description
Access	Dahua Two-door Access Controller DHI-ASC3202B
Controller	B (portable, indoor) The images, specifications and information mentioned in the document are only for reference, and might differ from the actual product.
