Network Cameras

Name: Network Cameras
Brand: Dahua
SKU: IPC-HDW2449T-S-PRO
Price: 170.19 EUR
Availability: BackOrder

Dahua

COD: IPC-HDW2449T-S-PRO Categorie: Telecamere IP, Videosorveglianza Tag: 4MP

170,19 € IVA inclusa

Prezzo precedente più basso negli ultimi 30 giorni: 340,38 €

Installatore o Rivenditore?
Registrati oppure Accedi per vedere il prezzo riservato.

Compara

Caratteristiche Specifiche tecniche Download

Telecamera IP Eyeball WizSense WizColor a focale fissa 4MP

> * I parametri e i datasheet riportati di seguito si applicano solo alla serie 2449-S1.

> Sensore di immagine CMOS 4 MP 1/1.8″, bassa illuminazione e immagine ad alta definizione.

> Uscita max. 4 MP (2688 × 1520) @20 fps, supporta 2560×1440 (2560 × 1440) @25/30 fps.

Datasheet

Scheda Tecnica

Manuali

Disegni

Disegni Dimensionali

Camera
Image Sensor	1/1.8" CMOS
Max. Resolution	2688 (H) × 1520 (V)
ROM	128 MB
RAM	256 MB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s–1/100,000 s
Min. Illumination	0.0001 lux@F1.0
S/N Ratio	>56 dB
Illumination Distance	Up to 30 m (98.43 ft) (Warm light)
Illuminator On/Off Control	Auto;Manual
Illuminator Number	2 (Warm light) Pan: 0°–360°
Angle Adjustment	Tilt: 0°–78° Rotation: 0°–360°
Lens
Lens Type	Fixed-focal
Lens Mount	M16
Focal Length	2.8 mm; 3.6 mm
Max. Aperture	F1.0 2.8 mm: H: 105°; V: 57°; D: 125°
Field of View	3.6 mm: H: 89°; V: 48°; D: 105°
Iris Control	Fixed 2.8 mm: 2.0 m (6.56 ft)
Close Focus Distance	3.6 mm: 3.0 m (9.84 ft)
Dori
Distance	*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
IVS (Perimeter Protection)	classification and accurate detection of vehicle and human);
SMD	SMD Plus Work together with Smart NVR to perform refine
Smart Search	intelligent search, event extraction and merging to event videos
Video
Video Compression	by the sub stream)
Smart Codec	Smart H.265+; Smart H.264+ Main stream: 2688 × 1520@(1–20 fps) /2560 × 1440@(1–25/30 fps) sub stream: 704 × 576 (1–25 fps)/704 × 480@(1–30 fps)
Video Frame Rate	*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Streaming Capability	2 streams 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 ×
Resolution	720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control	VBR;CBR H.264: 32 kbps–6144 kbps;
Video Bit Rate	H.265: 12 kbps–6144 kbps
Day/Night	Color/B/W
BLC	Yes
HLC	Yes
WDR	120 dB Auto; natural; street lamp; outdoor; manual; regional
White Balance	custom
Gain Control	Auto/Manual
Noise Reduction	3D NR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest (RoI)	Yes (4 areas)
Smart Illumination	Yes
Defog
Image Rotation	resolution and lower)
Mirror	Yes
Privacy Masking	4 areas
LDC	Yes
Audio
Built-in MIC	Yes, built-in Mic
Audio Compression	G.711a; G.711Mu; PCM; G.726
Alarm
Alarm Event	detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception
Network
Network Port	RJ-45 (10/100 Base-T)
SDK and API	Yes IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP;
Network Protocol	NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
Interoperability	ONVIF (Profile S & Profile G & Profile T & Profile M); CGI
User/Host	20 (Total bandwidth: 48 M)
Storage
Browser	IE; Chrome; Firefox
Management Software	Smart PSS Lite; DSS; DMSS
Mobile Client	iOS;Android Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509
Security	certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning
Power
Power Supply	12 VDC (±30%); PoE (802.3af) Basic: 1.7 W (12 VDC); 2 W (PoE);
Power Consumption	Max.: 4.9 W (12 VDC); 5.5 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity)
Environment
Operating Temperature	–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity	≤95% (RH), non-condensing
Storage Temperature	–40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity	≤95% (RH), non-condensing
Protection	IP67 Basic Protection *The products are designed for general use and are
Anti-corrosion Level	applicable even in areas with no specific requirements for anti-corrosion protection.
Structure
Casing Material	Cover: Plastic
Product Dimensions	109.5 mm × Φ109.9 mm (4.31" × Φ4.33")
Net Weight	0.39 kg (0.86 lb)
Gross Weight	0.56 kg (1.23 lb)
Ordering Information
Type	Model Description 4MP WizColor Fixed-focal
IP CAMERA	DH-IPC-HDW2449T-S-PRO Eyeball WizSense Network
Camera
Accessories (Optional)	DH-PFB305W Wall Mount Bracket DH-PFA150 Pole Mount Bracket DH-PFA152-E Pole Mount Bracket
Type	Model Description DH-PFB2203W Wall Mount Bracket DH-PFA13G Junction Box DH-PFM321-EN DC12V1A power adapter
Accessories (Optional)	DH-PFM320D-EN DC12V2A power adapter PFM900-E Integrated Mount Tester DHI-TF-W100-256GB MicroSD Card DHI-TF-P100/256GB MicroSD Card
Accessories
DH-PFA109	DH-PFA13G DH-PFA150
Mount Adapter	Junction Box Pole Mount Bracket
DH-PFA151	DH-PFA152-E DH-PFB2203W
Corner Mount Bracket	Pole Mount Bracket Wall Mount Bracket
DH-PFB220C	DH-PFB305W DH-PFM320D-EN
Ceiling Mount Bracket	Wall Mount Bracket DC12V2A power adapter
DH-PFM321-EN	DHI-TF-P100/256GB DHI-TF-W100-256GB
DC12V1A power adapter	MicroSD Card MicroSD Card
