Monitor DLED da 65" 4K UHD formato 16:9, risoluzione 3840×2160, contrasto 5000:1, luminosità 450 nit, angolo di visione 178°/178°, 2 HDMI 2.0, Ingressi: 2 HDMI 2.0, 2 USB 2.0, 1 VGA, 1 ingresso audio, 2 speaker 10 W, VESA 200×200 mm, alimentazione 100~240 Vac <145 W, operatività 24/7
Datasheet
Manuali
| Display | |
| Model | DHI-LM65-F400N |
| LCD Technology | VA |
| Backlight | DLED |
| Screen Size | 65 inch |
| Aspect Ratio | 16:9 |
| Viewing Size | 1428.48 (W) × 803.52 (H) mm |
| Screen-to-Body Ratio | ≥95% |
| Viewing Angle | 178° (H) / 178° (V) |
| Display Mode | Horizontal |
| Pixel Pitch | 0.372 mm × 0.372 mm |
| Pixels Per Inch | 68.32 |
| Resolution | 3840 (H) × 2160 (V) |
| Refresh Rate | 60 Hz |
| Display Color | 8 bit + FRC |
| Color Gamut | 72% NTSC |
| Brightness | 450 cd/m² (typ.) |
| Contrast Ratio | 5000:1 |
| Input Port | 1080@60 Hz), 2 × USB 2.0, 1 × Audio in, 1 × RS-232 in |
| Output Port | 1 × Audio out |
| Speaker | 2 × 10 W |
| Power Supply | 100–240 VAC (±10%), 50/60 Hz |
| Power Type | Built-in Power |
| Power Consumption | 101 W (basic), 138 W (typ.), 145 W (max) |
| Standby Power | <0.5 W |
| Operating Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
| Operating Humidity | 10%–85% (RH) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Storage Humidity | 5%–90% (RH) |
| General | |
| Product Dimensions | 3.22") (W × H × D), without base 1566 mm × 932 mm × 135 mm (61.65" × 36.69" × |
| Package Size | 5.31") (W × H × D) |
| Frame Width | U/L/R/D: 1.2 mm/1.2 mm/1.2 mm/14.8 mm |
| Net Weight | 13.15 kg (28.99 lb) |
| Gross Weight | 17.79 kg (39.22 lb) |
| Casing Color | Black |
| Control Mode | Remote Control, RS-232 |
| Status Indicator Light | Yes |
| Wall Mount VESA | 200 mm × 200 mm (7.87" × 7.87") Power cord, base, HDMI cable, remote control, user's |
| Accessory | manual, legal and regulatory information etc. |
| Optional Accessory | Wall mount |
| Ordering Information | |
| Type | Model Description Dahua 65" UHD LED |
| LED Monitor | DHI-LM65-F400N Monitor |
