Modulo relè, interconnessione wireless (fino a 24 dispositivi), Controllo tramite interruttore DIP switch, due contatti a potenziale zero (NO/NC), un ingresso a contatto pulito, alimentazione di rete e batteria ricaricabile di riserva
| Power Supply | AC 100-250V |
| Battery Back-up | 9V Lithium rechargeable (non-replaceable) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | ≤95% RH (non condensing) |
| Operating Frequency | 868MHz (-R8) /925 MHz (-R9) Up to 1000 m (3280.84 ft) in free air (-R8) |
| Radio Signal Range | Up to 500 m (1640.42 ft) in free air (-R9) AC 250V, 5A resistive, Continuous or Pulse |
| Contact Rating | mode |
| Output | 2 volt free contacts (NO/NC) |
| Input | 1 dry contact input |
| Maximum Number of | 24 |
| Standby Power Consumption | 20μA 700 hours without alarm when the battery is |
| Battery Life | fully charged |
| Dimensions | Φ144.4mm × 36.4mm (Φ5.69" × 1.43") |
| Weight | 232 g (Packaging is not included) |
| Certification | CE RCM , |
| Ordering Information | |
| Type | Model Description |
| Wireless Interconnected | Wireless Interconnected DHI-HY-MO5MA-R8 |
| Relay Module | Relay Module |
| Wireless Interconnected | Wireless Interconnected DHI-HY-MO5MA-R9 |
| Relay Module | Relay Module |
