OC-RAC-572700-33XN
ORCA – Armadio a pavimento 800X800X33U, 4 montanti, smontabile, piedini (zoccolo optional), portata 500 kg Nero
The Orca floor and wall cabinets are designed and manufactured in compliance with quality and safety standards, optimal solutions for the management and organization of structured cabling.
Caratteristiche
- Material: Realized in 15/10 Steel painted.
- Colour: Surface finish Black RAL 9011.
- Frame: Load-bearig frame
- Load: Static load capacity 800Kg.
- IP Grade: IP20 protection degree in according to EN 60529
- Doors front: Front, single door, perforated 75%
- Doors rear: Rear, vertical double door, perforated 75%
- Doors: Reversible, with quick release hinges system, foldaway handle and 2 key supplied
- Doors open: Opening 180°
- Side: Blind Panel
- Roof and floor: Roof with predisposition for mounting 2-3-4 fans ventilation unit; passive ventilation slots for the recirculation of hot air; pre-punched space for cable inlet
- Other: Front and rear 19″ in 20/10 galvanized steel side uprights adjustable in depth, pitch 46mm with intermediate pitches of 15,875mm; 2 front vertical cable management
Optional
- Finishing: Finishing plinth H100mm with removable panels
- Wheels: Wheels and wheels with brake
Certification
-
UNI EN ISO 9001, IEC 271 part 1,2,3, EN 61439-1, EN 60529, EN 62208 Empty enclosures for low-voltage switchdear and controlgear assemblies
